1. Epson DX5 print head adopted (water base & eco solvent), it has 8 lines nozzles, every line contains 182 nozzles. The resolution can reach up 1440dpi, it’s applicable both indoor and outdoor.
2. high quality damper equipped, it can filter the solid particles, which can prevent then print head from beginning plugged. Replaceable damper reduce the cost of maintenance.
3. Original Epson ink station equipped, it advanced ink print head intelligent cleaning and humidity keeping. Maintenance work turns out to be much easier than before.
4. No resistance guide rail equipped, it’s stable and longevous, brings low noise when moving.
5. 4pcs of big cartridges supply inks separately for every line of nozzles, it ensures output with high speed & quality.
6. Steel wire transmission system improves the positioning of ink drops, thereby improving the printing quality.
model
|
Special-2650
|
Special-3350
|
Print head
|
Piezo technology, Epson DX5 print head
|
Nozzle
|
182 nozzles*8lines/head
|
ink
|
Water base ink/ Eco solvent ink
|
Color model
|
Double CMYK
|
Material
|
Coated paper, photo paper/ PVC, flex, banner/ PP
|
Max material width
|
2500mm
|
3200mm
|
Max print width
|
2500mm
|
3200mm
|
Speed and resolution
|
720*1080 dpi
|
3pass
|
18.0m*m/h
|
720*1440 dpi
|
4pass
|
15.0m*m/h
|
720*2880dpi
|
8pass
|
6.0m*m/h
|
interface
|
USB2.0
|
power
|
AC100-120V, AC 200-240V, 50-60HZ
|
Dimension (L*W*H)
|
3550*1250*700mm
|
4250*1250*650mm
|
Package
|
Wooden, 3600*760*650mm
|
Wooden, 4300*760*650mm
|
|
|
|
|
|
